4G Network Radio, Solve the traditional communication distance issue , which delivers more flexibility and convenience.T-X21 is suitable all kind of networks.
Product Origin:
ChinaItem NO.:
T-X21Shipping Port:
QuanzhouColor:
GreyPayment:
T/T,PayPal,Western UnionMOQ:
24G Network Radio Walkie Talkies Long Range 100 Miles with PTT Button
This 4G Network Radio Solve the traditional communication distance issue , which delivers more flexibility and convenience. T-X21 is suitable all kind of networks.
Quick Details
Support 4G network
Support Group Call, Single Call , Friendly Call, Emergency Call
Ultra-thin Design
RTOS System
Side key assignment
GPS(optional)
Specification
|
General |
Dimensions (H*W*D) |
119mm*57mm*26mm |
|
Weight(Includes battery) |
≈134G(without antenna) |
|
|
Working temperature |
-30℃~+75℃ |
|
|
Operating Voltage |
DC3.3V-4.2V(Recommended value 3.8V) |
|
|
Working current |
Peak current ≈0.6A |
|
|
Average current |
≈540mA@UMTS2100:≈239mA@GSM900 |
|
|
Stand-by current |
≈5mA@UMTS:≈5mA@GSM |
|
|
Battery Capacity |
1500Mah |
|
|
Charger mode |
Type-c |
|
|
Baseband |
(U) SIM/SIMU |
Dual Sim Card, Standard SIM Card Slot: Support 3VSIM Card and 1.8VSIM Card |
|
UART Connector |
8 pins UART |
|
|
Maximum power consumption |
≈ 2.2uw |
|
|
Frequency |
LTE Frequency Band |
Eur Asia Band: FDD:B1/ 3/ 5/ 7/ 8/ 20/ 28 TDD:B38/ 40/ 41 North/South America Band: FDD:B2/ 3/ 4/ 5/ 7/ 8/ 28/ 66 |
|
TX Power |
LTE: +22dBm (3GPP TS 36.101 R9 Class 3) |
|
|
RX Sensitivity |
LTE: +22dBm (3GPP TS 36.101 R9 Class 3) |
4G Network Radio
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express:door to door service DHL,UPS, FEDEX, TNT and so on.
By air:To destination airport, need to assist clear customs, without door to door service.
By sea:To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days
