T-800,Waterproof Radio, is long talk range analog radio. Its robust body and rich features both serve to make it an ideal choice for security workers,construction sites and many more fields of work.
Product Origin:
ChinaItem NO.:
T-800Color:
BlackPayment:
T/T,PayPal,Western Union5W Powerful Hidden Display 199 Channels Walkie Talkie Portable VHF/UHF Waterproof Radio
T-800,Waterproof Radio, is long talk range analog radio. Its robust body and rich features both serve to make it an ideal choice for security workers,construction sites and many more fields of work.
Quick Details
Frequency 136-174MHZ/400-480MHZ
Hidden display 199 channels
Output power 5W/1W
CTCSS/DCS decode & encode, support non-standard CTCSS/DCS
Individual call, group call, all call
PTT ID, ANI
2 Tone &5 tone
Remote Kill , Stun, Activate & Revive
signaling 1750Hz
Scrambler
Compander
VOX function
Record function
Wide/Narrow Bandwidth 12.5KHZ/25KHZ
Emergency Alarm
Busy Channel Lock
Transmitter Time-out Timer(TOT)
Side Key Assignment
0-9 Grades Squelch Level Setting
Waterproof IP67(optional)
Vibration (optional)
Noise cancelling (optional)
Specification
GENERAL |
|
Frequency Range |
136-174MHz/400-480MHz |
Antenna |
High Gain Antenna |
Frequency Stability |
±2.5ppm |
Memory Channel |
199 Channels |
Working voltage |
DC 7.4V |
Antenna Impedance |
50Ω |
Operating Mode |
simplex of co-frequency or alien |
Dimensions |
116*61*38mm |
Li-in Battery Capacity |
2000MAH or 1500MAH (Type-c) |
TRANSMIT PART |
|
RF power |
5W |
Modulate Mode |
F3E |
Max.Freq.Deviation |
≤5KHz |
Remain Wave Radiation |
≤60db |
Transmitting Current |
≤1000mah |
RECEIVER PART |
|
Sensitivity |
<0.20uV (12dB SINAD) |
Squelch Sensitivity |
<0.20uV |
Intermodulation Antijamming |
50db |
Audio Power output |
500mW |
Receiving Current |
≤100mh |
Squelch Standby |
20ma |
Waterproof Radio
Service
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days.
Email us with any questions or inquiries or use our contact data. We would be happy to answer your questions.
