Product Origin:
ChinaItem NO.:
T-UV3DColor:
BlackPayment:
T/T,PayPal,Western UnionHigh Power Long Range Wireless Ham Dual Band Walkie Talkie Handy Talky
Quick Details
1.Output power:5w
2.Frequency range:136-174mhz &350-390MHZ &400-480mhz
3.Dual band, dual display, dual standby
4.2*128 channels storage
5.Emergency alert
6.FM radio and 25 stations storage
7.CTCSS/DCS scanning
8.0~9 grades VOX selectable
9.Multi and priority channel scan function
10.Channel name display and setting
11.Power on message display
12.Frequency difference setting
13.PC software programmable, Wired clone function
14.Reverse frequency
15.Wide/Narrow Band(25kHz/12.5kHz)
16.Busy channel lock-out(BCLO)
17.Transmitter time-out timer(TOT)
18.End-tone Elimination
19.LED setting
20.Beep setting
21.Transmit over beeper
22.Dual monitor
23.Receive power saving
24.Battery power voltage
25.Repeater shift direction
26.Frequency spacing function
27.Shortcut menu operation mode
28.High/Low TX power selectable
29.PTT-ID
30.DTMF
31.2tone
Specification
GENERAL |
|
Frequency Range |
136-174MHz/350-390MHz/400-480MHz |
Operating Temperature |
-20℃to +55℃ |
Frequency Combination |
please lock frequency synthesize |
Frequency Stability |
±2.5ppm |
Memmory Channel |
2*128channel |
Working Voltage |
7.4v |
Antenna Impedance |
50Ω |
Operating Mode |
simplex of co-frequency or alien |
Dimensions |
122*60*38mm |
Weight |
232g |
TRANSMIT PART |
|
RF power |
5w |
Modulate Mode |
F3E |
Max.Freq.Deviation |
≤5KHz |
Remain Wave Radiation |
<-60dB |
Transmitting Current |
≤1000mA |
RECEIVER PART |
|
Sensitivity |
<0.20uV (12dB SINAD) |
Squelch Sensitivity |
<0.20uV |
Intermodulation Antijamming |
50dB |
Audio Power output |
500mW |
Receiving Current |
≤100mA |
Squelch Standby |
20mA |
Ham Dual Band Walkie Talkie Handy Talky
