Long distance radio communication,with shockproof,waterproof and dustproof,T-850 portable radio is specifical customized for users in industries,which Harsh, noisy and dusty working conditions in megaproject and construction sites may lower your efficiency.
Product Origin:
ChinaItem NO.:
T-850Shipping Port:
QuanzhouColor:
BlackPayment:
T/T,PayPal,Western UnionProfessional Security Long Range Communication Two Way Radio
Long distance radio communication,with shockproof,waterproof and dustproof,T-850 portable radio is specifical customized for users in industries,which Harsh, noisy and dusty working conditions in megaproject and construction sites may lower your efficiency.
Quick Details
1.10W/5W/2W Power Switch with Side-key operation
2.Chinese/English Voice Announcement
3.Wide/Narrow Bandwidth Selection 12.5KHz/25KHz
4.CTCSS&DCS non-standard code
5.Battery Saver
6.Low Battery Alert
7.Check battery capacity by handheld operation and will annouce the capacity in current status
8.VOX on/off, VOX level setting, VOX delay time setting
9.DTMF/PTT ID
10.Busy Channel Lockout
11.Scan, Auto scan, Priority Channel Scan, Scan Add, Scan Delete
12.TX Power Level Adjustment by hand operation
13.Monitor / Monitor Momentary
14.Squelch level report, Squelch level adjustment
15.TOT function
16.Emergency Alarm
17.2 Tone
18.Remote Kill,Stun,Activate&Revive
19.Tail Tone Eliminate
20.Auto Power Off
21.Wire Clone
22.PC Software Program
Specification
|
GENERAL |
|
|
Frequency Range |
136-174MHz/400-480MHz |
|
Operating Temperature |
-20℃to +55℃ |
|
Frequency Combination |
please lock frequency synthesize |
|
Frequency Stability |
±2.5ppm |
|
Memory Channel |
16 |
|
Working voltage |
7.4V |
|
Antenna Impedance |
50Ω |
|
Operating Mode |
different-frequency simplex or same-frequency simplex |
|
Dimensions |
122*60*38mm |
|
Weight |
232g |
|
TRANSMIT PART |
|
|
RF power |
10w |
|
Modulate Mode |
F3E |
|
Max.Freq.Deviation |
≤5KHz |
|
Remain Wave Radiation |
<-60dB |
|
Transmitting Current |
≤1000mA |
|
RECEIVER PART |
|
|
Sensitivity |
<0.20uV (12dB SINAD) |
|
Squelch Sensitivity |
<0.20uV |
|
Intermodulation interference |
50dB |
|
Audio Power output |
500mW |
|
Receiving Current |
≤100mA |
|
Squelch Standby |
20mA |
Long distance radio communication
