Beside all the conventional analog radio,dual-mode DM-860UV bring you a whole new set of digital fature, man down, 1024 channels, 64 zone, 2 slots, versatile call , remote kill/revive, and a clear digital audio.
Product Origin:
ChinaItem NO.:
DM-860UVShipping Port:
QuanzhouColor:
BlackPayment:
T/T,PayPal,Western UnionLong Range 10W Output Dual Band DMR Digital Radio
Dual Band DMR Digital Radio,beside all the conventional analog radio,dual-mode DM-860UV bring you a whole new set of digital fature, man down, 1024 channels, 64 zone, 2 slots, versatile call , remote kill/revive, and a clear digital audio.
Quick Details
1.136-174MHZ & 400-480MHZ
2.1024Channels
3.CSV Contacts 150000; Contacts 1000
4.Digital Contacts (All call & Group call & Single call)
5.Alarm Function
6.Scan Function
7.Wide/Narrow bandwidth Selection
8.High/Middle/ Low Power Switch
9.Noise Cancelling
10.DTMF/Remote Kill, Stun, Activate & Revive
11.CTCSS/DCS
12.Encryption:ARC4 AES128 AES256
13.Side key Function
14.Chinese/English/Russia Voice prompt
15.Duplex Repeater Function
16.Talk Around
17.MAN DOWN
18.Output power 10W
19.Record （Function）
Specification
|
GENERAL |
|
|
Frequency Range |
136-174MHZ & 400-480MHZ |
|
Operating Temperature |
-30°C~ +60°C |
|
Storage temperature |
-40°C~ +85°C |
|
channel spacing |
Analog: 12.5/20/25KHz Digital: 12.5KHz |
|
battery life |
About 15/20 hours according to 5-5-90 duty cycle |
|
Memory Channel |
1024ch |
|
Working voltage |
7.2V DC ± 10% |
|
Antenna Impedance |
50Ω |
|
Frequency Stability |
±2.5ppm |
|
Dimensions |
136*65*40MM (without antenna) |
|
Weight |
265g |
|
TRANSMIT PART |
|
|
RF power |
low/Hi:5W/10W; |
|
4FSK Digital Modulate Mode |
12.5KHz : 7K60FXD(Data Only)/12.5KHz: 7K60FXE(Voice & Data) |
|
Frequency stability |
±1.5ppm |
|
Frequency modulation noise |
-40dB@12.5KHZ |
|
RF radiation |
<-36dBm@1GHz >- 30dBm@1GHz |
|
FM modulation mode |
12.5KHz:11F0F3E |
|
Modulation limitation |
2.5KHz@12.5KH |
|
Audio response |
+1dB-3dB |
|
Rated audio distortion |
≤3% |
|
Digital protocol |
ETSITS102361-1,-2,-3 |
|
Vocoder |
C7000 |
|
RECEIVE PART |
|
|
Analog sensitivity |
0.35uV/-116dBm(20dB SINAD) 0.22uV/-120dBm |
|
Digital sensitivity |
0.3uV/-117.4dBm(BER 5%) 0.7uV/-110dBm(BER 1%) |
|
Channel spacing |
12.5kHZ |
|
Frequency stability |
±1.0ppm |
|
intermodulation |
TIA603C:65dB ETSI:65dB |
|
Adjacent channel selectivity |
TIA603C:60dB@12.5KHZ ETSI:65dB@12.5KHZ |
|
Common channel suppression |
12Db@@12.5KHZ |
|
Spurious response suppression |
TIA603C:70Db ETSI:70dB MAILTO:60dB @12.5KHZ |
|
RX RF radiation |
<-57dBm@1GHz >- 47dBm@1GHz |
|
Blocking |
84dB |
|
Rated audio power |
1W |
|
Audio response |
+1dB-3dB |
|
Rated audio distortion |
≤ 3% |
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea: To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days
Email us with any questions or inquiries or use our contact data. We would be happy to answer your questions.
