Durable and innovative commerical radio, clear audio quality, dimension 115*55*25mm which makes it ideal for most commercial applications.
Product Origin:
ChinaItem NO.:
T-518Shipping Port:
QuanzhouColor:
BlackPayment:
T/T,PayPal,Western UnionMOQ:
2CE FCC Certification T-518 FRS/GMRS Walkie Talkies Two-Way Radios
Durable and innovative commerical radio, clear audio quality, dimension 115*55*25mm which makes it ideal for most commercial applications.
Quick Details
1.Frequency Range: VHF136-174MHz/UHF400-480MHz
2.16 Memory Channels
3.Output Power:5W
4.Priority Scan
5.PC Software Programmable, Encrypted Programming Software
6.VOX Function
7.CTCSS/DCS
8.Chinese and English Voice Prompt
9.Power Saving Function
10.High/Low Power Selective
11.Wide/Narrow Bandwidth Selective
12.End-tone Elimination
13.Emergency Alarm
14.Whispering Function
15.Busy Channel Lock
16.Transmitter Time-out Timer(TOT)
17.Side Key Assignment
18. 0-9 Grades Squelch Level Setting
19.IP66
20.ANI
21.PTT-ID
22.1200mAH Li-ion Battery
Specification
GENERAL |
|
Frequency Range |
136-174MHz/400-480MHz |
Operating Temperature |
-25℃~+55℃ |
Frequency Combination | Phase lock frequency synthesize |
Frequency Stability |
±2.5ppm |
Memory Channel |
16 Channels |
Working voltage |
7.4v |
Antenna Impedance |
50Ω |
Operating Mode |
simplex of co-frequency or alien frequency |
Dimensions |
113 x 55 x 32mm |
Weight |
232g(include battery pack) |
TRANSMIT PART |
|
RF power |
5w |
Modulate Mode |
F3E |
Max.Freq.Deviation |
≤5KHz |
Remain Wave Radiation |
<-60dB |
Transmitting Current |
≤1000mA |
RECEIVER PART |
|
Sensitivity |
<0.20uV (12dB SINAD) |
Squelch Sensitivity |
<0.20uV |
Intermodulation Antijamming |
50dB |
Audio Power output |
500mW |
Receiving Current |
≤100mA |
Squelch Standby |
20mA |
5W Two Way Radios
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.Prev :
