Mini Walkie Talkie Wireless Belt Clip Headset Radio

Mini Walkie Talkie Wireless Belt Clip Headset Radio

Belt Clip Mini Walkie Talkie, W1-4 is an innovation  mini portable radio, creative antenna desgin, 20 channels, 5 voice level selection, easy to carry!

  • Product Origin:

    China
  • Item NO.:

    W1-4
  • Shipping Port:

    Quanzhou
  • Color:

    Black
  • Payment:

    T/T,PayPal,Western Union
Product Detail

Mini Walkie Talkie Wireless Belt Clip Headset Radio

Belt Clip Mini Walkie Talkie,W1-4 is an innovation  mini portable radio, creative antenna desgin, 20 channels, 5 voice level selection, easy to carry!


Quick Details

UHF 400-480MHZ
20 Channels
Output Power 1W
5 Level Volume Adjustment
81*18*15mm


Specification

GENERAL

Frequency Range

 400-480MHz

Operating Temperature

 -20℃to +55℃

Frequency Combination

 please lock frequency synthesize

Frequency Stability

 ±2.5ppm

Memory Channel

20

Working voltage

 3.7V

Antenna Impedance

 50Ω

Operating Mode

simplex of co-frequency or alien

Dimensions

81*18*15mm

Weight

 95g


TRANSMIT PART

RF power

 1W

Modulate Mode

 F3E

Max.Freq.Deviation

≤5KHz

Remain Wave Radiation

 <-60dB

Transmitting Current

 ≤1000mA


RECEIVER PART

Sensitivity

 <0.20uV (12dB SINAD)

Squelch Sensitivity

<0.20uV

Intermodulation interference

50dB

Audio Power output

 500mW

Receiving Current

 ≤100mA

Squelch Standby

 20mA


Belt Clip Mini Walkie Talkie


Service


Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days

OEM order: 7-15 days after receiving your deposit and confirm sample package design.


Shipping


Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea: To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days.
A free consultation

Email us with any questions or inquiries or use our contact data. We would be happy to answer your questions.
